　　螺旋輸送機是一種利用電機帶動螺旋回轉，推移物料以實現輸送目的的機械。它能水平、傾斜或垂直輸送，具有結構簡單、橫截面積小、密封性好、操作方便、維修容易、便于封閉運輸?shù)葍?yōu)點。　　A screw conveyor is a mechanical device that uses an electric motor to drive a screw to rotate and move materials to achieve conveying purposes. It can transport horizontally, obliquely, or vertically, and has the advantages of simple structure, small cross-sectional area, good sealing, easy operation, easy maintenance, and convenient enclosed transportation.　　螺旋輸送機工作原理：　　當螺旋軸轉動時，由于物料的重力及其與槽體壁所產生的摩擦力，使物料只能在葉片的推送下沿著輸送機的槽底向前移動。物料的主要前進動力是來自螺旋葉片在軸向旋轉時將物料沿葉片切線方向向上和向前的作用力。　　When the spiral shaft rotates, due to the gravity of the material and the frictional force generated between it and the groove wall, the material can only move forward along the bottom of the conveyor groove under the push of the blades. The main forward force of the material comes from the force exerted by the spiral blades when rotating axially, which moves the material upwards and forward along the tangent direction of the blades.　　螺旋輸送機分類：【電話/微信咨詢：陳經理18068546632】　　螺旋輸送機從輸送物料位移方向的角度劃分，螺旋輸送機分為水平式螺旋輸送機和傾斜式螺旋輸送機兩大類型。　　From the perspective of material displacement direction, screw conveyors are divided into two types: horizontal screw conveyors and vertical screw conveyors.　　傾斜式螺旋輸送機　　傾斜螺旋輸送機的螺旋體的轉速比普通螺旋輸送機的要高，加入的物料在離心力的作用下，與機殼間產生了摩擦力，該摩擦力阻止物料隨螺旋葉片一起旋轉并克服了物料下降的重力，從而實現了物料的傾斜輸送。該機輸送量小，輸送高度小，轉速較高，能耗大。特別適宜輸送流動性好的粉粒狀物料,主要用于提升物料，提升高度一般不大于8米?！　he rotation speed of the spiral body of a vertical screw conveyor is higher than that of a regular screw conveyor. The added material generates frictional force between the machine casing under the action of centrifugal force, which prevents the material from rotating with the spiral blades and overcomes the gravity of the material's descent, thus achieving vertical transportation of the material. This machine has a small conveying capacity, a small conveying height, high rotational speed, and high energy consumption. Especially suitable for conveying powder and granular materials with good fluidity, mainly used for lifting materials, with a lifting height generally not exceeding 8 meters.　　水平螺旋輸送機：　　當物料加入固定的機槽內時，由于物料的重力及其與機槽間的摩擦力作用，堆積在機槽下部的物料不隨螺旋體旋轉，而只在旋轉的螺旋葉片推動下向前移動，如同不旋轉的螺母沿著轉動的螺桿作平移運動一樣，達到輸送物料的目的。該機便于多點裝料與卸料，輸送過程中可同時完成混合、攪拌或冷卻功能。對超載敏感，易堵塞;對物料有破碎損耗，水平螺旋輸送機的結構簡單，便于安裝和維修以及故障處理。適用于水平或微傾斜(20o以下)連續均勻輸送松散物料?！　hen the material is added to a fixed machine slot, due to the gravity of the material and its frictional force with the slot, the material piled up at the bottom of the slot does not rotate with the spiral body, but only moves forward under the push of the rotating spiral blades, just like a non rotating nut moving along the rotating screw, achieving the purpose of conveying the material. This machine is convenient for multi-point loading and unloading, and can simultaneously complete mixing, stirring, or cooling functions during the conveying process. Sensitive to overload and prone to blockage; The horizontal screw conveyor has a simple structure and is easy to install, maintain, and troubleshoot due to material crushing and loss. Suitable for continuous and uniform conveying of loose materials horizontally or slightly inclined (below 20 o).　　螺旋輸送機應用范圍：　　螺旋機廣泛應用于各行業，如化工、建材、電力、冶金、煤礦炭、糧食等行業，適用于水平或傾斜輸送粉狀、粒狀和小塊狀物料，如煤礦、灰、渣、水泥、糧食等，物料溫度小于200℃。螺旋機不適于輸送易變質的、粘性大的、易結塊的物料。在混凝土攪拌站中,螺旋輸送機的作用得到了很好的體現?！　piral machines are widely used in various industries, such as chemical, building materials, electricity, metallurgy, coal mine charcoal, grain, etc. They are suitable for horizontal or inclined conveying of powdered, granular, and small materials, such as coal mine, ash, slag, cement, grain, etc., with material temperatures below 200 ℃. Spiral machines are not suitable for conveying materials that are prone to spoilage, high viscosity, and clumping. The role of screw conveyors is well demonstrated in concrete mixing plants.　　螺旋輸送機優點:【電話/微信咨詢：陳經理18068546632】　　具有橫截面尺寸小，結構簡單，密封性能良好，中間多點裝料和卸料，操作方便，成本較低等優點?！　t has the advantages of small cross-sectional size, simple structure, good sealing performance, multiple loading and unloading points in the middle, convenient operation, and low cost.　　公司在強化企業管理的基礎上，依靠科技進步提高技術含量，先進的生產加工設備，領 先的管理理念，高素質的員工團隊，有效的質量保障體系和完善的售后服務，為制造高品質的產品提供可靠的保證，極大的滿足了各行業的需求，深受廣大客戶的信賴?！　∥夜臼冀K堅持“質量第 一、用戶至 上”的宗旨，服務于社會，誠信于業界，竭誠歡迎世界各地的業界好友光臨指導，洽談合作。           《掃二維碼-添加 陳經理 微信-咨詢產品》　　On the basis of strengthening enterprise management, the company relies on technological progress to improve technological content, advanced production and processing equipment, leading management concepts, a high-quality staff team, an effective quality assurance system, and perfect after-sales service to provide reliable guarantees for manufacturing high-quality products, greatly meeting the needs of various industries, and deeply trusted by customers.　　Our company always adheres to the principle of "quality first, customer first", serves society, and is honest in the industry. We warmly welcome friends from all over the world to visit and guide us, and negotiate cooperation.

　　氣密封不銹鋼卸料閥防止軸兩端漏料。用來控制粉體或顆粒物料的閥門，具有使用方便、可靠的特點，廣泛應用于各種行業中。氣密封卸料閥的氣封結構對其密封性能起著非常關鍵的作用?！　蜗蚯懈顨饷芊馐侵冈陂y門上設置一個單向切割結構，用來保持閥門的密封性能。這種結構簡單易用，不易磨損。但是，當顆粒物料反向沖擊時，會影響氣封效果?！　‰p向切割氣密封是指在閥門上設置兩個相互切割的結構，用來保持閥門的良好氣密性。這種結構具有較好的密封性能，不受顆粒物料反向沖擊的影響。但是，它的密封性受制于材料本身，易受到高溫和高壓的影響?！　《鄬託饷芊饨Y(jié)構是指在閥門上設置多層氣密封結構，用來保持閥門的良好氣密性和耐磨性。這種結構具有較好的耐磨性和密封性能，廣泛應用于各種需要高度密封和耐磨的行業中。　　旋轉密封閥可以根據使用需求，將壓縮空氣流量分配到不同的設備中，從而維持系統的壓力穩定，保證設備運行的正常?！　he airtight stainless steel discharge valve prevents material leakage at both ends of the shaft. Valves used to control powder or granular materials have the characteristics of convenient and reliable use, and are widely used in various industries. The sealing structure of the airtight discharge valve plays a crucial role in its sealing performance.　　Unidirectional cutting gas seal refers to the installation of a unidirectional cutting structure on the valve to maintain the sealing performance of the valve. This structure is simple, easy to use, and not easily worn. However, when the particle material is impacted in the opposite direction, it will affect the sealing effect.　　Bidirectional cutting gas seal refers to the installation of two mutually cutting structures on the valve to maintain good airtightness. This structure has good sealing performance and is not affected by the reverse impact of particle materials. However, its sealing performance is limited by the material itself and is easily affected by high temperature and high pressure.　　Multi layer gas sealing structure refers to the installation of multiple layers of gas sealing structure on the valve to maintain good airtightness and wear resistance of the valve. This structure has good wear resistance and sealing performance, and is widely used in various industries that require high sealing and wear resistance.　　The rotary seal valve can distribute compressed air flow to different equipment according to usage requirements, thereby maintaining stable system pressure and ensuring normal equipment operation.

　　風送式旋轉閥壓力范圍：2kg/cm2系統壓力或壓差?！　≡龃笕肟?出口：正方形，沒有截面尺寸對料流的限 制從而可達高產量?！　∑胀ㄐ停航Y(jié)構緊湊，占用空間小。　　軸承外置式：有效的防止粉塵侵入軸承，增大設備適應較高溫度的使用范圍?！　◎?qū)動方式：鏈驅動/馬達直聯驅動?！　?dòng)力配置：擺線針輪減速機、Y系列電機(可按客戶指定動力配置)?！　〔馁|(zhì)選項：碳鋼/鑄鐵/不銹鋼/鋁合金/陶瓷系列等?！　〕Ｖ萃美麢C(jī)械廠擁有多年的研發生產/定制卸料閥旋轉閥的經驗，秉承質量第 一、用戶至 上的原則。我們的旋轉閥能夠處理鋰電池、鋼廠、電廠、水泥、礦山、環保、塑料、化工、食品和醫藥等行業的各種顆粒、片狀、塊狀物料、粉料、超微粉體等?！　ressure range: 2kg/cm 2 System pressure or differential pressure.　　Increase the inlet/outlet: square, with no restrictions on material flow due to cross-sectional size, achieving high production.　　Normal type: compact structure, occupying small space.　　External bearing type: effectively prevents dust from entering the bearing, increasing the equipment's adaptability to higher temperature usage range.　　Drive mode: chain drive/motor direct drive.　　Power configuration: cycloidal pinwheel reducer, Y-series motor (can be configured according to customer specifications).　　Material options: carbon steel/cast iron/stainless steel/aluminum alloy/ceramic series, etc.　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production, and customization of discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valve can handle various types of particles, flakes, blocks, powders, and ultrafine powders in industries such as lithium batteries, steel mills, power plants, cement, mines, environmental protection, plastics, chemicals, food, and pharmaceuticals.

　　旋轉供料器(又稱電動鎖氣器、旋轉閥、星形下料器)廣泛地應用于中低壓氣力輸送系統中，它有定量供料與鎖氣的功能。它利用壓縮空氣或羅茨鼓風機作為氣源將物料從一個點輸送到另一個點的技術，具有可以將由數點集中的物料送往一處或有一處送往分散的數點，并實現輸送等特點，具有粉體輸送等作用，常用于化工、鍛造、半導體、玻纖等行業。旋轉供料器主要由主閥(殼體,端蓋,葉輪,密封結構等),電機減速機,防護裝置(鏈輪,鏈輪罩等),排氣口等組成。　　本卸料裝置是除塵設備排灰、送風和其它設備給料的主要設備，適用于粉狀物料和顆粒狀物料?！　∧猃埿D(zhuǎn)供料器采用加厚葉輪設計，與殼體配合間隙小，結構精密，使用過程中不易漏風不易漏料，防堵耐用。　　密封優越，用感無憂：結構穩定，密封性能良好?？捎糜诜哿稀⑿☆w粒物料，在正負極壓差吸送過程中將物料分離排出?！　〈水a(chǎn)品由本公司自主研制，適用于不可接觸金屬物料的卸料。箱體、葉輪以及端蓋，都采用整塊尼龍銑削加工，結構牢靠，運行無噪音，相較于陶瓷閥，可以節省成本，是鋰電行業新寵?！　otating feeders (also known as electric air locks, rotary valves, and star shaped feeders) are widely used in medium and low pressure pneumatic conveying systems, with the function of quantitative feeding and air locking. It uses compressed air or Roots blower as a gas source to transport materials from one point to another. It has the characteristics of being able to transport materials concentrated by points to one or scattered points, and achieve conveying. It has the function of powder conveying and is commonly used in industries such as chemical, forging, semiconductor, fiberglass, etc. The rotary feeder mainly consists of the main valve (shell, end cover, impeller, sealing structure, etc.), motor reducer, protective device (sprocket, sprocket cover, etc.), exhaust port, etc.　　This discharge device is the main equipment for dust removal equipment, ash discharge, air supply, and other equipment feeding, suitable for powdered and granular materials.　　The nylon rotary feeder adopts a thickened impeller design, with small clearance with the shell, precise structure, and is not prone to air leakage or material leakage during use, making it resistant to blockage and durable.　　Superior sealing and worry free use: stable structure and good sealing performance. Can be used for powder and small particle materials, to separate and discharge materials during the positive and negative pressure difference suction process.　　This product is independently developed by our company and is suitable for unloading non-contact metal materials. The casing, impeller, and end cover are all processed using a single piece of nylon milling, with a reliable structure and noiseless operation. Compared to ceramic valves, they can save costs and are a new favorite in the lithium battery industry.

　　尼龍旋轉卸料閥由本公司自主研制，適用于不可接觸金屬物料的卸料。箱體、葉輪以及端蓋，都采用整塊尼龍銑削加工，結構牢靠，運行無噪音，相較于陶瓷閥，可以節省成本，是鋰電行業新寵?！　〔捎眉雍袢~輪設計，與殼體配合間隙小，結構精密，使用過程中不易漏風不易漏料，防堵耐用?！　∶芊鈨?yōu)越，用感無憂：結構穩定，密封性能良好。可用于粉料、小顆粒物料，在正負極壓差吸送過程中將物料分離排出?！　he nylon rotary discharge valve is independently developed by our company and is suitable for unloading non-contact metal materials. The casing, impeller, and end cover are all processed using a single piece of nylon milling, with a reliable structure and noiseless operation. Compared to ceramic valves, they can save costs and are a new favorite in the lithium battery industry.　　Adopting a thickened impeller design, the clearance between the impeller and the shell is small, the structure is precise, and it is not easy to leak air or materials during use, and it is durable and anti clogging.　　Superior sealing and worry free use: stable structure and good sealing performance. Can be used for powder and small particle materials, to separate and discharge materials during the positive and negative pressure difference suction process.

　　卸料閥可分為：普通型，耐壓型，外裝耐溫耐壓型，快速清洗型，定量型?！　】焖偾逑葱停嚎焖偾逑葱D(zhuǎn)閥制作精致、成功使用德、日技術制造之精華。產品拆裝靈活、易于清洗。主要用于化工、制藥、食品等行業高衛生標準的物料卸料及經常更換物料的場所工作?！　】刹鹦度~輪：便于快速拆卸清洗旋轉閥的物料接觸面?！　◎?qū)動方式：鏈驅動/馬達直連驅動?！　?dòng)力配置：擺線針輪減速機，Y系列電機(可按客戶指定動力配置)?！　〔馁|(zhì)：改性尼龍系列?！　∧猃埿读祥y適用于鋰電正極材料輸送，高鎳三元材料，磷酸鐵鋰。閥體、端蓋外表面采用304.物料接觸8-10mm氧化鋁陶瓷工藝等。都可以滿足工況耐磨，耐溫尤為突出?！　he discharge valve can be divided into: ordinary type, pressure resistant type, external temperature and pressure resistant type, quick cleaning type, and quantitative type.　　Rapid cleaning type: the rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as chemical, pharmaceutical, and food, as well as working in places where materials are frequently replaced.　　Detachable impeller: facilitates quick disassembly and cleaning of the material contact surface of the rotary valve.　　Drive mode: chain drive/motor direct connection drive.　　Power configuration: cycloidal pinwheel reducer, Y-series motor (can be configured according to customer specifications).　　Material: Modified nylon series.　　Nylon discharge valve is suitable for transporting lithium battery positive electrode materials, high nickel ternary materials, and lithium iron phosphate. The outer surface of the valve body and end cover adopts 304 material contact 8-10mm alumina ceramic technology, etc. Both can meet the wear resistance requirements of working conditions, with outstanding temperature resistance.

適用于常規物料的正壓負壓輸送卸料，加工精度高，漏氣系數小，下料穩定。

根據使用方的要求，依據物料屬性、使用工況，專注定制關風機卸料閥。

根據使用方的要求，依據物料屬性、使用工況，專注定制關風機卸料閥。

我公司研制的靜電噴涂專用卸料閥，解決因關風機的問題導致除塵器的運行不暢，維護簡單，使用壽命增加，使用成本降低。
